The Minimum Ventilation Control Switch monitors the operation of the fan to make sure that the space is receiving the correct amount of ventilation per ASHRAE 62.2.

Hooded wall cap with rectangular duct connection designed for outside wall applications. Constructed of steel with black enamel finish, units feature built-in birdscreen and damper.

Transformers are available for applications requiring voltage reduction. Selection is based on motor amperage. Rated for 115 to 230/277V, 8.6A.

Wall louvered discharge with anodized aluminum grille designed for exterior applications. Units feature built-in damper to eliminate backdrafts.

Model RFC-7 roof cap accessory includes weather-tight aluminum construction with an integral birdscreen and built-in flashing flange.

Switches may be used on model SP and CSP fans to enable manual control of your fan or fan and light combination. Two single pole combination switch assembly rated for 120V, 15A. UL Listed.

Switches may be used on model SP and CSP fans to enable manual control of your fan or fan and light combination. Single pole rocker switch assembly rated for 120-277V, 15A. UL Listed.

Transformers are available for applications requiring voltage reduction. Selection is based on motor amperage. Rated for 115 to 230/277V, 2.0A.

Switches may be used on model SP and CSP fans to enable manual control of your fan or fan and light combination. Single pole light combination switch assembly rated for 120V, 15A. UL Listed.

Brick vents provide a permanent means of ventilation for crawl spaces, hung ceilings, incinerator rooms, chimney flues, foundations, pipe spaces and corridors. Extruded construction provides a quality finished appearance. A high water stop at the rear and deep overlapping blades with storm stops provide maximum resistance to rain and weather.

• Anodized aluminum construction
• Built in aluminum mesh insect screen

Dehumidistats are available with models SP and CSP fans to ventilate humid spaces. The sensor automatically detects excess humidity and activates a ventilation fan for control of excess condensation. There are automatic, manual, or air cycle modes. This can replace a single pole switch for control of a ventilating fan.

Durable plastic transition duct reducer that reduces fan outlet from 6 inches to 4 inches.

When the temperature in the space rises above the set point of 50 F - 90 F the contacts close and the thermostat will signal the fan to come on in order to exhaust air from the space. Includes face mounted thermometer that displays room temperature.

Transformers are available for applications requiring voltage reduction. Selection is based on motor amperage. Rated for 115 to 230/277V, 6.5A.

Speed controls are used for manual adjustment of the fan’s performance (for final system balancing) or to control the fan’s output in confined spaces, such as conference or meeting rooms. The fan can be adjusted to 60% of design airflow with a speed control. This reduction in airflow and fan speed is also accompanied by a reduction in noise level. Note: For use on direct drive fans with single phase, PSC or shaded pole motors.

Vibration isolation kit for suspended installation to minimize vibration, ensuring quiet operation.

Adjustable for temperature ranges between 30ºF to 110ºF (-1ºC to 43ºC), 120V, 16 amp

Pitched roof cap discharge accessory constructed of steel with black enamel finish. Includes integral flashing flash, built-in birdscreen and damper.

Time delay switches save energy by automatically turning off equipment. They may be used with SP and CSP fans or fan and light combinations for extended operating time of fan. Time delay switches act in the same manner as a standard switch, however, there is a delay of 10 to 60 minutes after the fan has been turned off.

Speed controls are used for manual adjustment of the fan’s performance (for final system balancing) or to control the fan’s output in confined spaces, such as conference or meeting rooms. The fan can be adjusted to 60% of design airflow with a speed control. This reduction in airflow and fan speed is also accompanied by a reduction in noise level. Note: For use on direct drive fans with single phase, PSC or shaded pole motors.

Motion detectors use a passive infrared motion detector to automatically turn the fan on when a change in motion is sensed. They have a viewing area of 180 degrees, however they must be placed in the line-of-sight. May be used with SP and CSP fans or fan/light combinations.

Hooded wall cap with round duct connection designed for outside wall applications. Constructed of aluminum, units feature built-in birdscreen and damper.

Transformers are available for applications requiring voltage reduction. Selection is based on motor amperage. Rated for 115 to 230/277V, 4.3A.

NEMA-1 rated disconnect switch provides positive electrical shutoff and safety. Disconnect switches are a recommended and necessary safety feature for every fan. Mounted directly on the fan, within sight and reach, disconnect switches provide the best protection against accidental startup during service or inspection.

Model MS-16 is a 1 Pole, single throw wall mount manual starter with pilot light. This starter supports up to 1/2 HP, 120 Volt, 1 Phase and includes a face plate.

Model RCC-7 roof cap accessory includes weathertight aluminum construction with an integral birdscreen and built-in curb cap. Requires roof curb (sold separately).
