Motion detectors use a passive infrared motion detector to automatically turn the fan on when a change in motion is sensed. They have a viewing area of 180 degrees, however they must be placed in the line-of-sight. May be used with SP and CSP fans or fan/light combinations.

Brick vents provide a permanent means of ventilation for crawl spaces, hung ceilings, incinerator rooms, chimney flues, foundations, pipe spaces and corridors. Extruded construction provides a quality finished appearance. A high water stop at the rear and deep overlapping blades with storm stops provide maximum resistance to rain and weather.

• Anodized aluminum construction
• Built in aluminum mesh insect screen

The SP Ceiling Radiation damper protects fire rated ceilings and effectively blocks the spread of heat and flames through the building's ventilation system. This damper is UL Classified; rated at three to four hours fire resistance.

Dehumidistats are available with models SP and CSP fans to ventilate humid spaces. The sensor automatically detects excess humidity and activates a ventilation fan for control of excess condensation. There are automatic, manual, or air cycle modes. This can replace a single pole switch for control of a ventilating fan.

Switches may be used on model SP and CSP fans to enable manual control of your fan or fan and light combination. Single pole rocker switch assembly rated for 120-277V, 15A. UL Listed.

Switches may be used on model SP and CSP fans to enable manual control of your fan or fan and light combination. Single pole light combination switch assembly rated for 120V, 15A. UL Listed.

Switches may be used on model SP and CSP fans to enable manual control of your fan or fan and light combination. Two single pole combination switch assembly rated for 120V, 15A. UL Listed.

Pitched roof cap discharge accessory constructed of steel with black enamel finish. Includes integral flashing flash, built-in birdscreen and damper.

Model RCC-7 roof cap accessory includes weathertight aluminum construction with an integral birdscreen and built-in curb cap. Requires roof curb (sold separately).

Model RFC-7 roof cap accessory includes weather-tight aluminum construction with an integral birdscreen and built-in flashing flange.

Adjustable for temperature ranges between 30ºF to 110ºF (-1ºC to 43ºC), 120V, 16 amp

When the temperature in the space rises above the set point of 50 F - 90 F the contacts close and the thermostat will signal the fan to come on in order to exhaust air from the space. Includes face mounted thermometer that displays room temperature.

Transformers are available for applications requiring voltage reduction. Selection is based on motor amperage. Rated for 115 to 230/277V, 2.0A.

Hooded wall cap with round duct connection designed for outside wall applications. Constructed of aluminum, units feature built-in birdscreen and damper.

Hooded wall cap with rectangular duct connection designed for outside wall applications. Constructed of steel with black enamel finish, units feature built-in birdscreen and damper.

Wall louvered discharge with anodized aluminum grille designed for exterior applications. Units feature built-in damper to eliminate backdrafts.
